Designer source image. It may show an installed part, prototype or render; it is not an Orphaned Parts production sample.
Magnetic Tow Hitch Cover
Magnetic Tow Hitch Cover design listed for 2020–2025 Tesla Model Y. Listed category: exterior. Verify dimensions, fitment and material suitability before printing.
- Make
- Tesla
- Model
- Model Y
- Year range
- 2020–2025
- Submodel
- Not supplied
- Engine
- Not supplied
Source approval status: pending. Source flags do not certify fit, material suitability or safety for your vehicle.
This listing is not offered for sale. Commercial permission or application suitability needs review.
Description
So I started to design my own one :-) Behind the European Model Y Version of the tow cover, the tow hitch has an inlet which is a kind of fixed in the hole of the tow hitch. The basic idea was to redesign the inlet to fit magnets into it and put a plate at the rear site of the tow hitch cover which also holds magnets. Then the cover ideally could be fixed by the magnetic force. The final step was two cut all the small hooks at the cover it self. Do not worry, it will not fell off, the magnet is know replace this force. Last but not least, the cover could be easily opened by hitting one site and the other site just pops off, without any tool and scratches in any surface.
I ordered 20mm diameter (3mm height) Neodym Magnets, where I fixed 2 in the tow-inlet AND also 2 in the plate and glued it.
I also added the STEP files, so feel free to create a Remix, help to make this better.
Source description, under the recorded CC-BY-SA-4.0 license.
Print instructions
- Layer height: 0.2mm
- Infill: 70%
- Supports: As needed
Settings from the source; not independently tested by Orphaned Parts.
Print price estimates
Planning prices for one print, not a final quote. Defaults use a size allowance inferred from the part name, not a measured or sliced model. Filament suitability must be confirmed.
| Filament | USD / print | Application notes |
|---|---|---|
| PLA | $28.50 | Indoor prototypes; not a default material for hot vehicle interiors. |
| PETG | $29.00 | General-purpose candidate; heat and creep need review. |
| ASA | $32.50 | Candidate for UV exposure; verify temperature and geometry. |
| ABS | $31.50 | Enclosed printing; review application and dimensions. |
| TPU | $37.50 | Flexible designs only; not a substitute for rigid materials. |
| Nylon | $37.50 | Moisture, tolerances and application require review. |
| PA-CF | $42.50 | Filled nylon; abrasive filament and fit need review. |
Cost examples only. This design is not offered for sale; permission or specialist application review is required.
Pricing assumptions and exclusions
USD: ($6 setup + $3 finishing + filament weight × assumed spool cost × 1.25 waste allowance + print hours × $2.50 × material time factor) ÷ 0.65. Rounded up to the next $0.50.
Assumed spool costs per kg: PLA $25, PETG $30, ASA $40, ABS $30, TPU $45, Nylon $65, PA-CF $95. Time factors: PLA/PETG 1.0, ASA/ABS 1.2, TPU 1.6, Nylon 1.4, PA-CF 1.5. These are proposed shop rates, not measured production costs.
Design work, test fitting, hardware, shipping and tax are additional where needed. Multi-file sets may need several prints. Use actual sliced weight and time when available. Final pricing is confirmed in writing.
