Design by 67stang · Original design · CC-BY-SA-4.0 · Source details. Indexed via 3DCarParts. Source text and images remain credited to their creators; no modified design files supplied.
Designer source image. It may show an installed part, prototype or render; it is not an Orphaned Parts production sample.
Center Console Cup Holder
Center Console Cup Holder design listed for 2005–2013 BMW 3 Series. Listed category: interior. Verify dimensions, fitment and material suitability before printing.
- Make
- BMW
- Model
- 3 Series
- Year range
- 2005–2013
- Submodel
- Not supplied
- Engine
- Not supplied
Source approval status: pending. Source flags do not certify fit, material suitability or safety for your vehicle.
License conditions, files, application and fit are reviewed before work is accepted.
Description
If you are like me and have had a E90 BMW for any length of time you might have asked yourself why did BMW make the worthless cubby into a cup holder. I know you guys with the idrive will be left out on this one but maybe it will help someone. I spent a lot of time and tried many times to get this as close as I could to a factory fit. This will fit into the factory clips console, but it will require trimming the console to fit a proper cup. I modeled this around the Yeti Tumbler and it think it seem to fit mose things well. With something like this you will need to print in a material that can handle the high temperatures of the cars interior. I printed mine in CarbonX which made for a very attractive finish for the BMW interior. I also used support which was a real pain to remove with the CarbonX.
I have included the cup holder file and the template to help scribe the console for cutting. I used a dremel cut off to remove the under structure around the cutout then a sanding wheel to match the curve on the cup holder. be sure to take your time and check the fit often. You will also need to trim just about 1mm off the three little supports in the bottom of the console so the cut holder will sit down all the way.
Source description, under the recorded CC-BY-SA-4.0 license.
Print instructions
- Layer height: 0.2mm
- Infill: 70%
- Supports: As needed
Settings from the source; not independently tested by Orphaned Parts.
Print price estimates
Planning prices for one print, not a final quote. Defaults use a size allowance inferred from the part name, not a measured or sliced model. Filament suitability must be confirmed.
| Filament | USD / print | Application notes |
|---|---|---|
| PLA | $42.50 | Indoor prototypes; not a default material for hot vehicle interiors. |
| PETG | $43.50 | General-purpose candidate; heat and creep need review. |
| ASA | $50.00 | Candidate for UV exposure; verify temperature and geometry. |
| ABS | $48.00 | Enclosed printing; review application and dimensions. |
| TPU | $60.50 | Flexible designs only; not a substitute for rigid materials. |
| Nylon | $60.00 | Moisture, tolerances and application require review. |
| PA-CF | $69.00 | Filled nylon; abrasive filament and fit need review. |
Pricing assumptions and exclusions
USD: ($6 setup + $3 finishing + filament weight × assumed spool cost × 1.25 waste allowance + print hours × $2.50 × material time factor) ÷ 0.65. Rounded up to the next $0.50.
Assumed spool costs per kg: PLA $25, PETG $30, ASA $40, ABS $30, TPU $45, Nylon $65, PA-CF $95. Time factors: PLA/PETG 1.0, ASA/ABS 1.2, TPU 1.6, Nylon 1.4, PA-CF 1.5. These are proposed shop rates, not measured production costs.
Design work, test fitting, hardware, shipping and tax are additional where needed. Multi-file sets may need several prints. Use actual sliced weight and time when available. Final pricing is confirmed in writing.
