Window Crank
Window Crank design listed for 1990 Mazda MX-5. Listed category: interior. Verify dimensions, fitment and material suitability before printing.
- Make
- Mazda
- Model
- MX-5
- Year range
- 1990
- Submodel
- Not supplied
- Engine
- Not supplied
Source approval status: pending. Source flags do not certify fit, material suitability or safety for your vehicle.
License conditions, files, application and fit are reviewed before work is accepted.
Description
IMPORTANT:
it must be assembled as in the photos. It is assembled using an M4 low cap steel bolt with a hex socket.
The lever knob comes together but doesn't turn very well. you have to force it in and turn it and after a while it works. It was a work in progress until I discovered aliexpress.
If you like this part please tip me I will use your donation to support my Mx5 build.
If you have question or you want to see my Mx5 search " nomoney_miata " on Instagram.
Thanks
Source description, under the recorded CC-BY-4.0 license.
Print instructions
- Layer height: 0.2mm
- Infill: 70%
- Supports: As needed
Settings from the source; not independently tested by Orphaned Parts.
