Designer source image. It may show an installed part, prototype or render; it is not an Orphaned Parts production sample.
SJ413 side marker 194 Reflector
SJ413 side marker 194 Reflector design listed for 1985–1995 Suzuki Samurai. Listed category: lighting. Verify dimensions, fitment and material suitability before printing.
- Make
- Suzuki
- Model
- Samurai
- Year range
- 1985–1995
- Submodel
- Not supplied
- Engine
- Not supplied
Source approval status: pending. Source flags do not certify fit, material suitability or safety for your vehicle.
License conditions, files, application and fit are reviewed before work is accepted.
Description
Needless to say you can see on the driver side picture it wasn't very visible. Now the passenger side one is with the new reflector and its a lot better looking even in broad daylight.
I used this https://www.dormanproducts.com/p-4124-85814.aspx for the bulb socket as it friction fits into the assembly with out issue.
Assembly as fallowed
Grommet 1 for body side
Housing put into grommet 1
Grommet 2 ontop of housing
Install factory Lens (printable lens will eventually come when verify screw heads fit correctly)
may be used on the rear but recommend using flex seal spray on the back of the reflector housing AND bulb socket together as one piece to reduce risk of water short out.
Source description, under the recorded CC-BY-4.0 license.
Print instructions
- Layer height: 0.2mm
- Infill: 70%
- Supports: As needed
Settings from the source; not independently tested by Orphaned Parts.
Print price estimates
Planning prices for one print, not a final quote. Defaults use a size allowance inferred from the part name, not a measured or sliced model. Filament suitability must be confirmed.
| Filament | USD / print | Application notes |
|---|---|---|
| PLA | $28.50 | Indoor prototypes; not a default material for hot vehicle interiors. |
| PETG | $29.00 | General-purpose candidate; heat and creep need review. |
| ASA | $32.50 | Candidate for UV exposure; verify temperature and geometry. |
| ABS | $31.50 | Enclosed printing; review application and dimensions. |
| TPU | $37.50 | Flexible designs only; not a substitute for rigid materials. |
| Nylon | $37.50 | Moisture, tolerances and application require review. |
| PA-CF | $42.50 | Filled nylon; abrasive filament and fit need review. |
Pricing assumptions and exclusions
USD: ($6 setup + $3 finishing + filament weight × assumed spool cost × 1.25 waste allowance + print hours × $2.50 × material time factor) ÷ 0.65. Rounded up to the next $0.50.
Assumed spool costs per kg: PLA $25, PETG $30, ASA $40, ABS $30, TPU $45, Nylon $65, PA-CF $95. Time factors: PLA/PETG 1.0, ASA/ABS 1.2, TPU 1.6, Nylon 1.4, PA-CF 1.5. These are proposed shop rates, not measured production costs.
Design work, test fitting, hardware, shipping and tax are additional where needed. Multi-file sets may need several prints. Use actual sliced weight and time when available. Final pricing is confirmed in writing.
