Designer source image. It may show an installed part, prototype or render; it is not an Orphaned Parts production sample.
Armrest Magnetic Lock Replacement
Armrest Magnetic Lock Replacement design listed for 1997–2006 Volkswagen Golf. Listed category: interior. Verify dimensions, fitment and material suitability before printing.
- Make
- Volkswagen
- Model
- Golf
- Year range
- 1997–2006
- Submodel
- Not supplied
- Engine
- Not supplied
Source approval status: pending. Source flags do not certify fit, material suitability or safety for your vehicle.
License conditions, files, application and fit are reviewed before work is accepted.
Description
I broke my original lock on the middle armrest, so I designed a magnetic replacement.
1. Preparing the First Piece
Sand down the remaining old plastic.
Cut away the rubber elements to ensure a clean and flat mounting surface.
2. Preparing the Second Piece
Remove the old lock mechanism.
Glue the new printed frame in its place.
When printing, add a manual pause at around the 100th layer to insert the magnets.
Magnet Specification
Type: Strong neodymium cylinder magnets
Size: 5×2 mm
Set: As used in the final assembly
Source description, under the recorded CC-BY-SA-4.0 license.
Print instructions
- Layer height: 0.2mm
- Infill: 70%
- Supports: As needed
Settings from the source; not independently tested by Orphaned Parts.
